modeli
RG-ES205GC-P
RG-ES206GC-P
RG-ES209GC-P
Anahtarlama kapasitesi
10Gb/sn
12Gb/sn
18Gb/sn
Önbelleği Değiştirme
1Mbit
1Mbit
1.5Mbit
Paket yönlendirme oranı
7.44Mp/sn
8.9Mp/sn
13.392Mp/sn
Limanlar
4 10/100/1000 Base-T bağlantı noktası (PoE/PoE+)
1 10/100/1000 Base-T yukarı bağlantı bağlantı noktası
4 10/100/1000 Base-T bağlantı noktası (PoE/PoE+)
2 10/100/1000 Base-T yukarı bağlantı bağlantı noktası
8 10/100/1000 Base-T bağlantı noktası (PoE/PoE+)
1 10/100/1000 Base-T uplink bağlantı noktası
PoE Standardı
IEEE 802.3at / 802.af
PoE Güç Bütçesi
54W
54W
120W
Hız / Dubleks modu
Otomatik / Yarım / Tam dubleks Hız otomatik / 10/ 100 /1000
Mac Adresi
2K
4K
4K
Maksimum VLAN Sayısı
16
İzin verilen VLAN kimliği
1 ~ 4094
Bağlantı noktası tabanlı VLAN
Destek
Akış kontrolü
Destek
Döngü Koruması
Destek
Bilinmeyen Tek Noktaya Yayın Bastırma
Destek
Çok Noktaya Yayın / Yayın Fırtına Bastırma
Destek
yansıtma
Çoktan Bire Yansıtma
Liman İzolasyonu
Destek
Kablo Testi
Destek
ICMP Ping'i
Destek
DNS
DNS İstemcisi
telnet
Destek
MACC
Destek
liman dalgalanması
Ortak mod: 4KV
Elektrostatik deşarj
Hava deşarjı
: 6KV Kontak deşarjı: 4KV
modeli
Özellikler
RG-ES205GC-P
RG-ES206GC-P
RG-ES209GC-P
Güç tüketimi
≤ 60W
≤ 60W
≤ 130W
Güç kaynağı
Harici güç adaptörü
100-240V
Boyutlar (G x D x Y)
148mm*78mm*26mm
148mm*78mm*26mm
202*108*28mm
Ağırlık
0,9 kg (paketle birlikte)
0,9 kg (paketle birlikte)
1,3 kg (paketle birlikte)
MTBF
>200K
Çalışma sıcaklığı
0 ila 40°C
Depolama sıcaklığı
-40~70ºC
Çalışma Nemi
%10 ila %90 BN
Depolama nemi
%5 ila %95 BN
Çalışma Yüksekliği
-500 ~ 5000 metre
FAN
fansız
Yönetmek
Web yönetim arayüzü, MACC bulut platformu ve mobil uygulama aracılığıyla yönetim ve konfigürasyon desteği
Güvenlik Standardı Toprak Direnci
GB4943-2011, EN 62638-1
EMC
GB9254-2008, EN 55032, EN61000-3-2, EN61000-3-3, EN 55035
modeli
RG-ES210GC-LP
RG-ES218GC-P
RG-ES226GC-P
Anahtarlama kapasitesi
20Gb/sn
36Gb/sn
52Gb/sn
Önbelleği Değiştirme
1.5Mbit
4.1Mbit
4.1Mbit
Paket yönlendirme oranı
14.8M/sn
26.8Mp/sn
38.7Mp/sn
Limanlar
8 10/100/1000 Base-T bağlantı noktası (PoE/PoE+),
2 10/100/1000 Base-T uplink bağlantı noktası
16 10/100/1000 Base-T bağlantı noktası (PoE/PoE+),
2 10/100/1000 Base-X SFP yukarı bağlantı bağlantı noktası
24 10/100/1000 Base-T bağlantı noktası (PoE/PoE+),
2 10/100/1000 Base-X SFP yukarı bağlantı bağlantı noktası
PoE Standardı
IEEE 802.3at / 802.af
PoE Güç Bütçesi
70W
240W
370W
Hız / Dubleks modu
Otomatik / Yarım / Tam dubleks Hız otomatik / 10/ 100 /1000
Mac Adresi
4K
8K
8K
Maksimum VLAN Sayısı
16
İzin verilen VLAN kimliği
1 ~ 4094
Bağlantı noktası tabanlı VLAN
Destek
Akış kontrolü
Destek
Döngü Koruması
Destek
Bilinmeyen Tek Noktaya Yayın Bastırma
Destek
Çok Noktaya Yayın / Yayın Fırtına Bastırma
Destek
yansıtma
Çoktan Bire Yansıtma
Liman İzolasyonu
Destek
Kablo Testi
Destek
ICMP Ping'i
Destek
DNS
DNS İstemcisi
telnet
Destek
MACC
Destek
liman dalgalanması
Ortak mod: 4KV
Elektrostatik deşarj
Hava deşarjı
: 6KV Kontak deşarjı: 4KV
Güç tüketimi
≤ 80W
≤ 280W
≤ 443W
Güç kaynağı
Harici güç adaptörü
100-240V
Dahili güç kaynağı
modeli
Özellikler
RG-ES210GC-LP
RG-ES218GC-P
RG-ES226GC-P
Boyutlar
(G x D x Y)
202 x 108 x 28 mm
300 x 230 x 43,6 mm
440 x 289 x 43,6 mm
Ağırlık
1,3 kg (paketle birlikte)
3,5 kg (paketle birlikte)
4,2 kg (paketle birlikte)
MTBF
>200K
Çalışma sıcaklığı
0 ila 40°C
Depolama sıcaklığı
-40~70ºC
Çalışma Nemi
%10 ila %90 BN
Depolama nemi
%5 ila %95 BN
Çalışma Yüksekliği
-500 ~ 5000 metre
FAN
fansız
Uyarlanabilir hız ayarını destekler. Ortam sıcaklığı 25°C'nin altına düştüğünde ve PoE gücü 120W'nin altına düştüğünde fan çalışmayı durdurur.
Yönetmek
Web yönetim arayüzü, MACC bulut platformu ve mobil uygulama aracılığıyla yönetim ve konfigürasyon desteği
Güvenlik Standardı Toprak Direnci
GB4943-2011, EN 62638-1
EMC
GB9254-2008, EN 55032, EN61000-3-2, EN61000-3-3, EN 55035
